If you need to supplant your shower faucet and cartridge, first you need to know how to place what you have.

Curology

Identifying the Brand/Manufacturer of Your Shower Faucet

Faucets used to be standardized and all accept like internal parts but for a different appearance and mode on the exterior. The replacement parts could be ordered from multiple suppliers, making for an easy fix. Today, most brands have their own specifications and parts.

Now there is variance in stems (cartridges), valves, and splines. Because of this, you will demand to know how to identify the brand of your faucet earlier you can prepare information technology. Knowing what you're working with makes it easier to disassemble and fix. Y'all tin begin this procedure past:

1. Looking for the brand.
2. Using a faucet cartridge identification (nautical chart).

Shower Faucet Type and Brand Identification

You lot can identify your faucet's make by looking for a mark that indicates who made information technology. Information technology will exist engraved, printed, or laser-etched. Some of the almost common brands are included in the table below.

Logos of Major Faucet Brands

American Standard	Blanco	Brizo
Chicago Faucets	Danco	Danze
Delta	Gerber	Glacier Bay
Grohe	Hansgrohe	Kohler
Moen	Newport Contumely	Peerless
Cost Pfister	Toto	—

Purchasing replacement parts for a faucet

bawl, CC BY 2.0, via flickr

What Kind of Shower Faucet Do I Have?

If y'all cannot locate any markings on the faucet, y'all'll need to starting time disassembling it. Begin with the handle. You lot'll be able to measure the cartridge (stem) length of the faucet or resort to the number of splines.

How to Take Apart a Shower Faucet

Step 1

First, start by turning off the water supply. This tin can exist done by locating the cut-off valves (there will be one for hot and one for common cold). If you are working on the shower, you volition accept to locate the main water valve for the firm which will be outside forth the firm or building.

Step 2

If you demand to remove the handle, you can do this by using a screwdriver fix (Allen wrenches work well). The blazon of screwdriver you need will depend on the type of handle:

• If y'all are working on a single-lever handle, yous volition take to locate a small prepare-crew in the handle and use an Allen wrench.
• If you lot are working with a crystal handle, there will likely be a plastic cover that y'all can pop off with a apartment-head screwdriver. There you will be able to access the stem with a Phillips screwdriver.
• If you are working with a faucet with two handles, remove the decorative cap/plastic cover (pry it off with a Phillips screwdriver).

Scroll to Proceed

Read More From Dengarden

Step three

Once the screws are removed, you can pull the stalk and handle out—they oft come out together. You may have to wiggle the stalk as you gently pull information technology out to fully disengage information technology.

Moen Disassembly and Installation Instructions

Effigy Out Where Your Faucet Is Leaking or Broken

Now information technology'due south fourth dimension to locate the issue at hand. If you are dealing with a leak, y'all will probable notice that the rubber O-ring or washers have worn out (oft due to age). Safety washer replacements are cheap and like shooting fish in a barrel to set up. Consider bringing your parts into the local hardware store (plumbing shops work well, besides). They will be able to place your faucet type and which part has failed. They can also assistance you with replacements.

How to Identify the Cartridge Make

You can also save money by identifying the cartridge brand. Do this past measuring the length and number of splines. Once you have this information, you tin compare them to a reference. Please have a look at this Interline Brand cartridge identification chart PDF.

How to Use a Faucet (Valve/Stem) Cartridge Identification Chart

1. Employ a caliper or ruler and measure the cartridge. Do this by measuring from the base to the tip (from seat to splines).
2. Pay attention to the length tier of your cartridge (Lengths range from 1–12).
3. Next, identify the broach pattern with the broach nautical chart (see folio B-5).
4. Find your stem'due south length tier (equally highlighted on the correct/left of each page).
5. Notice the matching broach design (alongside the cartridge photos). Make sure it is right.
6. Next, you lot volition take note of the part numbers that you will need.

Unlike types of shower faucets require different disassembly.

nick v, CC BY-SA 2.0, flickr

Additional Tips for Repairing Shower Faucets

• Pay attention to warranties: Go along all paperwork and documentation of your faucet type and model; if it's under warranty, you lot may qualify for free replacement parts if you contact the manufacturer.
• Know where your brand supplies: Brands like Pfister don't sell parts in local hardware stores; do check Amazon, however, as many parts can be found here and commitment time is as fast as one–3 days.
• Take notation of which parts are interchangeable: Continue in mind that some rubber seats, O-rings, and springs may not be interchangeable. They can look similar between brands, merely they may not be the same. Delta valve seats, for instance, await very like to Pfister's design, but the diameters are different which will definitely result in leaks and other issues.

This article is accurate and true to the all-time of the author's knowledge. Content is for informational or amusement purposes only and does not substitute for personal counsel or professional communication in business concern, financial, legal, or technical matters.

© 2019 Laynie H

Berk on July 12, 2020:

I want to replace my shower faucet just I do not know the make proper noun it says the messages HC but I don't know what make it is or any help
